EC800-LTE Vehicle Radio-Eevin-PoC Radio/Bodycam

Technical Specification

Key Specifications

Dimensions (L x W x H)

212×93×58mm

Weight

489 g (without power cable, bracket, or other accessories)

CPU

MTK octa-core processor, 2.0 GHz

Android 12

RAM

4GB RAM

ROM

64GB ROM

Display

LCD 5.99-inch WVGA IPS touchscreen, 1080 × 2160 resolution, serial backlight, sunlight readable. Supports wet-finger and glove touch (≤2.0 mm), rain/gesture operation, and multi-touch. 1.1 mm Corning Gorilla Glass (3rd gen) with AF coating

Card slot

Nano SIM card and Micro TF card

eSIM

Supports eSIM

WLAN

WIFI 802.11 a/b/g/n/ac, 2.4G/5G

Bluetooth

BT5.0

GNSS positioning (international)

GPS/AGPS/GLONASS/BEIDOU

GNSS positioning (domestic)

Supports BeiDou-only positioning

Battery

Vehicle power supply, DC 12–24V wide voltage / 3A

NFC

Button

Rotating knob button×1, SOS button×1, Custom button×4, Home button×1, ON/OFF button×1

Ports

Antenna interface (SMA) ×4, Type-C interface ×1, aviation interface (4-pin) ×2, aviation interface (10-pin) ×1, audio interface (3.5 mm) ×1, aviation interface (3-pin) ×1, RS232 interface ×1

Sensor Type

Gravity (accelerometer), proximity, ambient light, geomagnetic sensors

Audio & Video

Camera

Video Format

H.263, H.264 AVC, MPEG-4 SP, VP8, VP9

Image Format

JPG, GIF, BMP, PNG, WEBP

Speaker

5W high-power

AI noise reduction

AI noise reduction: no obvious feedback within ≥0.8 m, with effective noise suppression and filtering.

Durability

Work Temp.

-20℃ ~ 60℃

Storage Temp.

-40℃ ~ 80℃

Environmental Requirements

RoHS

IP Rating

IP67

Drop Resistance

1.2m

Featured Accessories

Standard Accessories

Vehicle mount bracket, vehicle power cable, external antenna, speaker microphone

Optional Accessories

EY60 external camera
